Буровой насос, Запасные части для бурового насоса
Параметры 4
| Модель | Внешний диаметр | Диаметр долота | Соединение | Заходность винтовой пары | Степень | Расход жидкости | Скорость вращения | Потери рабочего давления | Момент на выходе | Макс. потери давления | Макс. крутящий момент | Рабочее давление | Макс. давление | Мощность на выходе | ||||||||||
| мм | дюйм | мм | дюйм | л/с | гал/мин | Об./мин | МПа | psi | Н*м | Фунт силы-фут | МПа | Psi | Н*м | Фунт силы-фут | кН | Фунт-сила | кН | Фунт-сила | кВт | л.с. | ||||
| 5LZ43X7.0 -4 | 43 | 1 11/16 | 48- 76 | 1 7/8- 3 | 1 AMMT | 5:6 | 4 | 0.8- 1.6 | 13- 16 | 440- 870 | 3.2 | 464 | 55 | 41 | 4.48 | 650 | 77 | 57 | 3 | 660 | 6 | 1320 | 6.5 | 9 |
| 5LZ54X7.0 -3 | 54 | 2 1/8 | 60- 89 | 2 3/8- 3 1/2 | 1 1/2 REG | 5:6 | 3 | 1.7- 4 | 28- 65 | 280- 635 | 2.4 | 348 | 130 | 96 | 3.36 | 487 | 182 | 134 | 4 | 880 | 8 | 1760 | 11 | 15 |
| 5LZ73X7.0 -3 | 73 | 2 7/8 | 95- 121 | 3 3/4- 4 3/4 | 2 3/8 REG | 5:6 | 3 | 3- 10 | 50- 160 | 137- 458 | 2.4 | 348 | 450 | 332 | 3.36 | 487 | 630 | 465 | 12 | 2640 | 25 | 5500 | 22 | 29 |
| 5LZ73X7.0 -3.5 | 73 | 2 7/8 | 95- 121 | 3 3/4- 4 3/4 | 2 3/8 REG | 5:6 | 3.5 | 5- 8 | 80- 130 | 230- 366 | 2.8 | 406 | 526 | 388 | 3.92 | 569 | 736 | 543 | 12 | 2640 | 25 | 5500 | 25 | 33 |
| 5LZ79X7.0 -4 | 79 | 3 1/8 | 95- 121 | 3 3/4- 4 3/4 | 2 3/8 REG | 5:6 | 4 | 2.7- 9.6 | 75- 150 | 120- 430 | 3.2 | 464 | 615 | 454 | 4.48 | 650 | 861 | 635 | 12 | 2640 | 25 | 5500 | 36 | 48 |
| 5LZ89X7.0 -4 | 89 | 3 1/2 | 114- 149 | 4 1/2- 5 7/8 | 2 3/8 REG | 5:6 | 4 | 4- 13 | 60- 200 | 100- 320 | 3.2 | 464 | 1050 | 774 | 4.48 | 650 | 1470 | 1084 | 22 | 4840 | 35 | 7700 | 47 | 63 |
| 5LZ95X7.0-3 | 95 | 3 3/4 | 118- 149 | 4 5/8- 5 7/8 | 2 7/8 REG | 5:6 | 3 | 5- 13 | 80- 200 | 120- 300 | 2.4 | 348 | 850 | 627 | 3.36 | 487 | 1190 | 878 | 30 | 6600 | 55 | 12100 | 32 | 43 |
| 5LZ120X7.0 -4 | 120 | 4 3/4 | 149- 200 | 5 7/8- 7 7/8 | 3 1/2 REG | 5:6 | 4 | 10- 19 | 150- 300 | 120- 227 | 3.2 | 464 | 2302 | 1698 | 4.48 | 650 | 3223 | 2377 | 50 | 11000 | 100 | 22000 | 62 | 83 |
| 7LZ120X7.0 -3.8 | 120 | 4 3/4 | 149- 200 | 5 7/8- 7 7/8 | 3 1/2 REG | 7:8 | 3.8 | 10- 19 | 150- 300 | 77- 147 | 3.0 | 441 | 3376 | 2490 | 4.26 | 617 | 4726 | 3486 | 50 | 11000 | 100 | 22000 | 60 | 80 |
| 7LZ120X7.0 -3.8 ERT | 120 | 4 3/4 | 149- 200 | 5 7/8- 7 7/8 | 3 1/2 REG | 7:8 | 3.8 | 12- 23 | 190- 360 | 91- 170 | 3.8 | 551 | 5170 | 3813 | 5.7 | 827 | 7755 | 5720 | 50 | 11000 | 100 | 22000 | 94 | 126 |
| 5LZ165X7.0 -5 | 165 | 6 1/2 | 213- 251 | 8 3/8- 9 7/8 | 4 1/2 REG | 5:6 | 5 | 16- 28 | 250- 450 | 110- 190 | 4.0 | 580 | 5025 | 3706 | 5.6 | 812 | 7035 | 5189 | 80 | 17600 | 160 | 35200 | 104 | 140 |
| 7LZ165X7.0 -4.8 | 165 | 6 1/2 | 213- 251 | 8 3/8- 9 7/8 | 4 1/2 REG | 7:8 | 4.8 | 19- 38 | 300- 600 | 88- 176 | 3.8 | 557 | 7110 | 5244 | 5.38 | 780 | 9954 | 7342 | 80 | 17600 | 160 | 35200 | 146 | 195 |
| 5LZ172X7.0 -5 | 172 | 6 3/4 | 213- 251 | 8 3/8- 9 7/8 | 4 1/2 REG | 5:6 | 5 | 19- 32 | 300- 500 | 100- 174 | 4.0 | 580 | 6320 | 4661 | 5.6 | 812 | 8848 | 6526 | 100 | 22000 | 170 | 37400 | 115 | 154 |
| 7LZ172X7.0 -5 | 172 | 6 3/4 | 213- 251 | 8 3/8- 9 7/8 | 4 1/2 REG | 7:8 | 5 | 19- 38 | 300- 600 | 70- 140 | 4.0 | 580 | 9140 | 6741 | 5.6 | 812 | 12796 | 9438 | 100 | 22000 | 170 | 37400 | 140 | 187 |
| 5LZ172X7.0 -3 ERT | 172 | 6 3/4 | 213- 251 | 8 3/8- 9 7/8 | 4 1/2 REG | 5:6 | 3 | 19- 40 | 300- 630 | 100- 218 | 3.0 | 435 | 5680 | 4189 | 4.2 | 609 | 8520 | 6284 | 100 | 22000 | 170 | 37400 | 130 | 174 |
| 5LZ178X7.0 -5 | 178 | 7 | 213- 251 | 8 3/8- 9 7/8 | 4 1/2 REG | 5:6 | 5 | 16- 32 | 250- 500 | 70- 150 | 4.0 | 580 | 6320 | 4661 | 5.6 | 812 | 8848 | 6526 | 100 | 22000 | 170 | 37400 | 115 | 154 |
| 7LZ178X7.0 -5 | 178 | 7 | 213- 251 | 8 3/8- 9 7/8 | 4 1/2 REG | 7:8 | 5 | 20- 39 | 320- 620 | 80- 165 | 4.0 | 580 | 7200 | 5310 | 5.6 | 812 | 10080 | 7435 | 100 | 22000 | 170 | 37400 | 150 | 201 |
| 5LZ185X7.0 -5 | 185 | 7 1/4 | 222- 251 | 8 3/4- 9 7/8 | 4 1/2 REG Up 6 5/8 REG Down | 5:6 | 5 | 18- 32 | 280- 500 | 90- 180 | 4.0 | 580 | 5550 | 4093 | 5.6 | 812 | 7770 | 5731 | 100 | 22000 | 170 | 37400 | 130 | 174 |
| 5LZ197X7.0 -5 | 197 | 7 3/4 | 251- 311 | 9 7/8- 12 1/4 | 5 1/2 REG Up 6 5/8 REG Down | 5:6 | 5 | 18- 37 | 280- 580 | 75- 155 | 4.0 | 580 | 7000 | 5163 | 5.6 | 812 | 9800 | 7228 | 150 | 33000 | 200 | 44000 | 130 | 174 |
| 5LZ203X7.0 -5 | 203 | 8 | 251- 311 | 9 7/8- 12 1/4 | 6 5/8 REG Up 6 5/8 REG Down | 5:6 | 5 | 19- 38 | 300- 600 | 80- 162 | 4.0 | 580 | 8054 | 5940 | 5.6 | 812 | 11276 | 8316 | 155 | 34100 | 250 | 55000 | 130 | 174 |
| 7LZ203X7.0 -4 | 203 | 8 | 251- 311 | 9 7/8- 12 1/4 | 6 5/8 REG Up 6 5/8 REG Down | 7:8 | 4 | 19- 44 | 300- 700 | 47- 109 | 3.2 | 464 | 11089 | 8179 | 4.48 | 650 | 15525 | 11450 | 155 | 34100 | 250 | 55000 | 145 | 194 |
| 5LZ210X7.0 -5 | 210 | 8 1/4 | 251- 311 | 9 7/8- 12 1/4 | 6 5/8 REG | 5:6 | 5 | 20- 41 | 320- 650 | 70- 150 | 4.0 | 580 | 9000 | 6638 | 5.6 | 812 | 12600 | 9293 | 180 | 39600 | 300 | 66000 | 150 | 201 |
| 5LZ244X7.0 -5 | 244 | 9 5/8 | 311- 445 | 12 1/4- 17 1/2 | 6 5/8 REG | 5:6 | 5 | 30- 55 | 470- 870 | 60- 125 | 4.0 | 580 | 12000 | 8851 | 5.6 | 812 | 16800 | 12391 | 220 | 48400 | 330 | 72600 | 200 | 268 |
